Physical
Length: 425 mm (16.7 in.) without bracket
Width: 245 mm (9.6 in.) without bracket
Height: 240 mm (9.4 in.) without bracket
Weight: 7.5 kg (16.5 lbs.) without bracket
Dynamic Effects
Variable strobe: 0 - 650 ms (50 Hz supply), or 0 - 530 ms (60 Hz supply)
Strobe rate: 0 - 25 flashes/second (50 Hz supply),
0 - 30 flashes/second (60 Hz supply)
Strobe intensity: Blackout - maximum
Blinder effect: Continuous with auto fade
Special effects: Ramp up, ramp down, ramp up-down,
random flash, lightning, spikes, blinder, single flash
Control and Programming
Control options: DMX, stand-alone, multi-fixture chase (with Detonator remote), MC-1
Stand-alone control: Via N.O. or N.C. SPST switch
Stand-alone options: Selectable flash rate or blinder effect
Setting and addressing: DIP switch
DMX channels: 1, 3, and 4 channel modes
Receiver: RS-485
DMX compliance: USITT DMX512/1990
Lamp
Type: Xenon discharge
Approved lamps: MAX-15 Xenon (200-240 V power), MAX-7 Xenon (100-120 V power)
Construction
Housing: Steel
Color: Black
Finish: Electrostatic powder-coated
Connections
Power connection: 1.5 m (4.9 ft.) cable tail, 14 AWG
DMX data in/out: 3-pin and 5-pin XLR sockets
|
Electrical
AC power (MAX-7 model): 100-120 V nominal, 50/60 Hz
AC power (MAX-15 model): 200-240 V nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch-mode
Typical current consumption (MAX-15, high power mode): 8 A
Peak current consumption: 33 A
Main fuse (all AC power voltages): 20 AT (slow blow), 250 V
AC mains power cable: 14 AWG or 2.5mm2
Thermal
Maximum ambient temperature (Ta max.): 40° C (104° F)
Minimum ambient temperature (Ta min.): 5° C (41° F)
Maximum lamp socket temperature: 120° C (248° F)
Approvals
EU safety: EN 60598-1, EN 60598-2-17
EU EMC: EN 50 081-1, EN 50 082-1
US safety: ANSI/UL 1573
Canadian safety: CSA C22.2 No. 166
Included Items
MAX-15 Xenon lamp (installed, EU model): P/N 97010307
MAX-7 Xenon lamp (installed, US model): P/N 97010308
User manual: P/N 35000094
Accessories
G-clamp: P/N 91602003
Atomic Detonator: P/N 90760020
Atomic Colors for Atomic 3000: P/N 91611086
Half-coupler clamp: P/N 91602005
Spare Parts
MAX-15 lamp for use with 200-240 V power: P/N 97010307
MAX-7 lamp for use with 100-120 V power: P/N 97010308
Main fuse (20 AT): P/N 05020040
Ordering Information
Atomic 3000 DMX EU model (MAX-15 lamp, 200-240 V): P/N 90424200
Atomic 3000 DMX US model (MAX-7 lamp, 100-120 V): P/N 90424300
|
