Jbl VTX S28 2x18 inch 2x2000 Watt Peak Suspendable Subwoofer

Marka : Jbl
Fiyat : ₺0,00(KDV Dahil)

Components 2 x 2269H Differential Drive® 18"





Jbl VTX S28



Dual 18" Subwoofer - Suspendable

VTX series dual 18" subwoofers employ two 2269H 18" transducers featuring Differential Drive technology with two voice coils, two neodymium magnets and extremely high peak-to peak excursion capabilities to deliver extended very low frequency performance.
The VTX S28 can be suspended or ground-stacked and is cardioid-arrayable in either configuration for improved rear rejection. Compatible with VTX V25 suspension, S28 can be suspended at the top of V25 arrays to extend the effective low frequency line length, providing improved vertical pattern control combined with improved rear rejection when used in cardioid mode.
Alternatively, S28 arrays (cardioid or front-firing) can be suspended beside or behind V25 arrays. For theatrical sound design, S28 can be suspended in the middle of flown V25 arrays to facilitate balcony and floor coverage by allowing improved underbalcony penetration. Larger cardioid configurations are also effective where S28 is suspended or ground-stacked in multiple cardioid blocks, each block consisting of 3 enclosures (2 front-firing, 1 rear-firing).



Features

Aluminum front baffles for reduced cabinet
JBL’s patented Differential Drive®
Patented JBL S.A.F.E.TM Suspension System
Crown VRack DSP and Amplification
JBL HiQnet Performance ManagerTM System





DIFFERENTIAL DRIVE® TECHNNOLOGY

Enhanced Performance and Dramatically Reduced Driver Weight
JBL's exclusive dual voice coil, dual magnetic gap Differential Drive technology is at the core of all VTX models, dramatically reducing driver weight while greatly enhancing all critical performance parameters: frequency response, power output and distortion.
LEARN MORE


VTX S.A.F.E™ Suspension & Laser setup

Next Generation Line Array System Solutions.
JBL’s patented S.A.F.E suspension system is streamlined for speed and efficiency with improved hardware for faster setup with fewer pinning operations and greater security.
LEARN MORE



System Integration and Management

With the VTX Series you are not just using a product, you are gaining access to an expert system.

Tools for system design and all the components to analyze, configure, set up and control a VTX system are all part of the JBL commitment to total system integration and support.

The goal is maximum efficiency and the highest possible level of performance in any venue, anywhere in the world.
LEARN MORE



Özellikler

System Type Full Size Suspendable, Cardioid-Arrayable, Dual 18" Subwoofer with Ultra Long Excursion Transducers
Components 2 x 2269H Differential Drive® 18"
Frequency Range (-10 dB) 24 - 400 Hz
Nominal Section Impedances 2 x 8 ohms
Continuous Power Rating 2 x 2000W
Dimensions (W x H x D) 1222 mm x 493.3 mm x 926.5 mm (48.1" x 19.4" x 36.5")
Weight 83 kg (183 lb)


inç
18 inç
Impedance
8 ohm
Aktif-Pasif
Aktif
