Passive Speaker: VA42BM
System Type: 3.5" Passive Speaker System
Output Power: 120W Continuous, 240W Program, 480W Peak
Sensitivity (1W/1M): 95dB
Maximum SPL @ 1m: 122dB Max. (calculated)
Frequency Response (-6dB): 160Hz-20kHz
Impedance: 8 ohms
Transducer Low: 4 x 3.5" Woofer, 1" (25.4mm) Voice Coil
Crossover Frequency: 500Hz
Dispersion (-6dB): 100° Horizontal
Attachment Points: Adjustable Rigging System, Horizontal Splay Rotation in -90°-0°- 90° Increments from 180°
Enclosure Construction: Plywood Cabinet, Resistant Paint, Metal Grille with Foam
Mounting: 2 x Holder, 1 x Input Connector for VA-WP Pole, Another with Input Connector for VA42TP
Dimensions (HxWxD): 448 x 106.6 x 98mm
Net Weight: 3.48 kg
|
Passive Speaker: VA42TP
System Type: 3.5" Passive Speaker System
Output Power: 120W Continuous, 240W Program, 480W Peak
Sensitivity (1W/1M): 95dB
Maximum SPL @ 1m: 122dB Max.(calculated)
Frequency Response (-6dB): 160Hz-20kHz
Impedance: 8 ohms
Transducer Low: 4 x 3.5" Woofer , 1" (25.4mm) Voice Coil
Crossover Frequency: 500Hz
Dispersion (-6dB): 100° Horizontal
Attachment Points: Adjustable Rigging System, Horizontal Splay Rotation in -90°-0°- 90° Increments from 180°
Enclosure Construction: Plywood Cabinet, Resistant Paint, Metal Grille with Foam
Mounting: 1 x Holder, 1 x Input Connector for VA-42BM or VA-WP Pole
Dimensions (HxWxD): 422 x 106.6 x 98mm
Net Weight: 3.41 kg
|
Active Subwoofer: VA12SA
System Type: 12" Active Subwwofer Apeaker Cabinet
Frequency response -6 dB: 40Hz-500Hz
Total amplifier power: 1000W Continuous/2000W Program/4000W Peak Class D @ 4 Ohms
Amplifier, subwoofer: 500W Continuous / 1000W Program / 2000W Peak Class-D @ 4ohms
Amplifier, satellite / mid / high unit: 500W Continuous / 1000W Program / 2000W Peak Class-D @ 4ohms
Sensitivity (1W@1m): 96dB
Maximum SPL@1m: 130dB (Calculated)
Electronic Protections: Over heat Protection / Short Circuit Protection / Digital Compressor
Cooling: Temperature-controlled fan
Connections: Input: 2 Combo-XLR & 1/4", RCA In L & R, 1 XLR Thru & Mix out
External Controls: Volume Control / Switch for Input sens. / Swtich for mode selector / Power ON with Green LED / Limiter with Red LED / Ground Lift / IP Control
Power Supply: 110V/230V -50/60Hz
Enclosure Construction: Plywood cabinet, resistant black paint, metal grille with foam, rubber feet, handles
Mounting: Holder with Input Jacks for Pole
Dimensions (W x H x D): 430 x 450 x 480 mm
Net Weight: 20.51 kg
|
Pole: VA-WP
Enclosure Construction: Plywood Cabinet, Resistant Paint, Metal Grille with Foam
Mounting: 2 x Holder, 1 x Input Connector for Sub, Another with Input Connector for Satellite
Dimensions (WxHxD): 700 x 106.6 x 98mm
Net Weight: 2.70 kg
|
